COB-exact: timeline 1:1 from armmmkr.cob (activatescr/deactivatescr, disassembled with _cob_dis.py). StateChg staged-deploy family: 3 open stages, then the compiled close order — not a reversed activate. Fire/hit/death/smoke scripts are engine-driven or firing-only and not part of this loop.
Animation
PNG frames
Frame 0 / 1000.00 s
COB timeline (ARMMMKR.COB)
- 0.00–0.40 s — Closed rest pose (3DO zero point)
- 0.40–1.17 s — activatescr stage 1: lid2 x-turn 0.6°→30.4°, lid3 x-turn 0.0°→0.6°, lid3 x-turn 0.6°→-26.8°, mmakercore y-turn 0.0°→-30.4°
- 1.17–1.95 s — activatescr stage 2: mmakercore y-move 0.00 elmo→5.05 elmo, lid1 x-turn 0.0°→35.3°, lid4 x-turn 0.0°→-30.4°, lid2 x-turn 30.4°→60.8° …
- 1.95–3.50 s — activatescr stage 3: mmakercore y-move 5.05 elmo→15.85 elmo, mmakercore y-turn -60.8°→-90.0°
- 4.70–5.38 s — deactivatescr stage 1: mmakercore y-move 15.85 elmo→5.05 elmo, mmakercore y-turn -90.0°→-60.8°
- 5.38–6.07 s — deactivatescr stage 2: mmakercore y-move 5.05 elmo→0.00 elmo, lid1 x-turn 35.3°→0.0°, lid4 x-turn -30.4°→0.0°, lid2 x-turn 60.8°→30.4° …
- 6.07–7.44 s — deactivatescr stage 3: lid2 x-turn 30.4°→0.6°, lid3 x-turn -26.8°→0.6°, mmakercore y-turn -30.4°→0.0°
- 7.44–8.04 s — closed again — loop restarts (fire/hit/death scripts are engine-driven, not in this loop)
Every stage duration equals its COB sleep exactly; values are raw COB units (turns: BAM 65536 = 360°, moves: elmo × 163840). Renderer conversions follow the proven family conventions (_cob_anim.py).
