Advanced Torpedo Launcher (CORATL) Render Control

Animation (JavaScript)

The loop is played live in your browser from the validated loop table (the same data the reference render below was made from); the badge on the player is its self-test (seam + motion probes). A pre-rendered fallback image is embedded for no-JS viewers.

COB-exact: timeline 1:1 from coratl.cob (aim/fire (COB VM), disassembled with _cob_dis.py). StateChg staged-deploy family: 1 open stages, then the compiled close order — not a reversed activate. Fire/hit/death/smoke scripts are engine-driven or firing-only and not part of this loop.

COB timeline (CORATL.COB)

  • 0.00–0.40 s — Rest pose (3DO zero point)
  • 0.40–0.96 s — AimPrimary(8192, 3641): +45° yaw / +20° pitch at the COB aim speeds (concurrent)
  • 0.96–19.12 s — salvo: 4 shots at the weapon reloadtime (4400 ms) — barrels/flares alternate per the compiled toggle (barrel/coil1/coil2/coil3, barrel/coil1/coil2/coil3, barrel/coil1/coil2/coil3, barrel/coil1/coil2/coil3)
  • 19.12–19.12 s — AimPrimary(0, 0): back to the rest aim (the aim call the engine sends next; RestoreAfterDelay pacing is engine-driven)
  • 19.12–19.73 s — rest again — loop restarts seam-clean (frame N = frame 0, pixel-verified)

Every stage duration equals its COB sleep exactly; values are raw COB units (turns: BAM 65536 = 360°, moves: elmo × 163840). Renderer conversions follow the proven family conventions (_cob_anim.py).
